2007 NAKAMURA-TOME SUPER NTY3

NAKAMURA-TOME SUPER NTY3 2007

Serial # V100605

MACHINE SPECIFICATION

(3) TURRET CAPACITY 12 POSITIONS

X - AXIS TRAVEL (INCHES) 15.7" / 400MM

Y - AXIS TRAVEL (INCHES) 15.7" / 400MM

Z - AXIS TRAVEL (INCHES) 14.7" / 375MM

42MM/15HP 6000-RPM SP, L

42MM/15HP 6000-RPM RT, SPINDLE

6” KITAGAWA CHUCK NTY3

SPINDLE MOTOR (HP) 15/10 HP

MAX SWING (INCHES) 17.32"

DIST. BETWEEN CENTERS (INCHES) 7.87”

BAR STOCK CAPACITY 2.0"

PALLET SIZE (INCHES) 25"

TABLE SIZE - L 61"

TABLE SIZE - W 30"

THROAT DEPTH 9.45"

CHUCK SIZE (INCHES) 8"

MAX TURN DIAMETER 6.9”

MAX. TURNING LENGTH 23”

SLIDE TRAVEL X1 / X2 / X3 5.3”

SLIDE TRAVEL Z1 / Z2 / Z3 9.6” / 9.6” / 22.7”

SLIDE TRAVEL 3.1”

SLIDE TRAVEL B AXIS 24”

BOTH SPINDLE SPEED 6000 RPM

NO. OF TOOL STATIONS 12 - ½ indexing NO OF INDEX POSITIONS 24

ROTATING TOOLS 6000 RPM

MILLING MOTOR 5/3 HP

PARTS CATCHER “A”

PARTS CONVEYOR, NTY3

MANUAL TOOL PRESETTER

CHIP CONVEYOR

AIR BLOW RIGHT AND LEFT SPINDLE

MACHINE EQUIPPED WITH

FANUC 31I-A 3-PATH (WITH CONVERSATIONAL SOFTWARE) LNS BARFEED, HIGH PRESSURE COOLANT ATS 3J COLLET CLOSERS ON BOTH SPINDLES TOOL PRESETTER FOR BOTH SPINDLES PARTS CATCHER CHIP CONVEYOR
